Proudly Made by Durst Industries - Australia. |
|
|
#VALUE! |
|
#VALUE! |
|
|
Industry |
Automotive workshops and service centres |
Truck fleets, commercial vehicles, buses, and industrial machinery |
Truck fleets, commercial vehicles, buses, and industrial machinery |
Mining equipment, trucks, buses, and industrial machinery with engine sizes up to 30 litres |
Mining equipment, trucks, buses, and industrial machinery with engine sizes up to 30 litres |
All 12/24V mining grade vehicles to 80L engine size |
24Volt only Mining grade vehicles 80L and above engine size |
Voltage |
12 Volt only |
Dual Voltage - 12/24 Volts. |
24 Volt Only |
Dual Voltage - 12/24 Volts. |
24 Volt Only - Available backup power via 2 x 20ah Lithium Batteries. |
Dual Voltage 12/24V |
24 Volt only |
CCA Equivalent / Peak Amps |
CCA 1600 - 1800 amps Peak Amps ~10,000 A |
CCA 1600 - 1800 amps Peak Amps ~10,000 A |
CCA 1600 - 1800 amps Peak Amps ~10,000 A |
CCA 1600 - 1800 amps Peak Amps ~10,000 A |
CCA 1600 - 1800 amps Peak Amps ~10,000 A |
CCA 3500 - 4000 amps Peak Amps ~14000 A |
CCA 5000+ amps Peak Amps ~16000 A |
Stored Energy |
36.5 WH 12 x 3000F Capacitors |
36.5 WH 12 x 3000F Capacitors |
36.5 WH 12 x 3000F Capacitors |
36.5 WH 12 x 3000F Capacitors |
36.5WH + 512 WH |
73 WH 24 x 3000F Capacitors |
109 WH 36 x 3000F Capacitors |
Starting Method |
Supercapacitor-based, battery-less |
Supercapacitor-based, battery-less |
Supercapacitor-based, battery-less |
Supercapacitor-based, battery-less |
Supercapacitor-based, battery-less. Additional 2 x 20AH LiFePo4 Batteries as back up power |
Supercapacitor-based, battery-less |
Supercapacitor-based, battery-less |
Cycle Life |
1,000,000 Cycles |
1,000,000 Cycles |
1,000,000 Cycles |
1,000,000 Cycles |
1,000,000 Cycles up to 3 years on the Lithium Batteries |
1,000,000 Cycles |
1,000,000 Cycles |
Control Features |
Auto-reset fuse, reverse polarity warning, anti-spark/anti-spike filtering, built-in volt meter, 350 amp Anderson receptacle |
Auto-reset fuse, reverse polarity warning, anti-spark/anti-spike filtering, built-in volt meter, 350 amp Anderson receptacle |
Auto-reset fuse, reverse polarity warning, anti-spark/anti-spike filtering, built-in volt meter, 350 amp Anderson receptacle |
Auto-reset fuse, reverse polarity warning, anti-spark/anti-spike filtering, built-in volt meter, CAT receptacle |
Auto-reset fuse, reverse polarity warning, anti-spark/anti-spike filtering, built-in volt meter, CAT receptacle |
Auto-reset fuse, reverse polarity warning, anti-spark/anti-spike filtering, built-in volt meter, CAT receptacle |
Auto-reset fuse, reverse polarity warning, anti-spark/anti-spike filtering, built-in volt meter, CAT receptacle |
Enclosure |
Powder Coat Aluminium |
Powder Coat Aluminium |
Powder Coat Aluminium |
Powder Coat Aluminium |
Powder Coat Aluminium |
Powder Coat Aluminium |
Powder Coat Aluminium |
Dimensions / Weight |
321 x 210 x 435mm, 15 kg |
321 x 210 x 435mm, 15 kg |
321 x 210 x 435mm, 15 kg |
321 x 210 x 435mm, 16 kg |
321 x 210 x 675 25kg |
321 x 210 x 675 27kg |
320 x 20 x 750 33kg |
Output Connector |
350 Amp Anderson |
350 Amp Anderson |
350 Amp Anderson |
CAT Receptacle |
CAT Receptacle |
CAT Receptacle |
CAT Receptacle |
Cable Set |
50mm2 Dual Insulation Multistrand Copper Superflex- Anderson to Clamp. 1.5 and 3 Metre lead sets and Custom length Lead Sets available at extra cost. |
50mm2 Dual Insulation Multistrand Copper Superflex- Anderson to Clamp. 1.5 and 3 Metre lead sets and Custom length Lead Sets available at extra cost. |
50mm2 Dual Insulation Multistrand Copper Superflex- Anderson to Clamp. 1.5 and 3 Metre lead sets and Custom length Lead Sets available at extra cost. |
70mm2 Dual Insulation Multistrand Copper Superflex - CAT receptacle to Clamp. 1.5 , 3 Metre and Custom Lead Sets available at extra cost. |
70mm2 Dual Insulation Multistrand Copper Superflex - CAT receptacle to Clamp. 1.5 , 3 Metre and Custom Lead Sets available at extra cost. |
70mm2 Dual Insulation Multistrand Copper Superflex - CAT receptacle to Clamp. 1.5 , 3 Metre and Custom Lead Sets available at extra cost. |
70mm2 Dual Insulation Multistrand Copper Superflex - CAT receptacle to Clamp. 1.5 , 3 Metre and Custom Lead Sets available at extra cost. |
Lead Set Part Numbers |
LS-15-AL 1.5 metre Anderson to Clamp LS-30-AL 3 metre Anderson to Clamp |
LS-15-AL 1.5 metre Anderson to Clamp LS-30-AL 3 metre Anderson to Clamp |
LS-15-AL 1.5 metre Anderson to Clamp LS-30-AL 3 metre Anderson to Clamp |
LS-15CC 1.5M CAT to CAT LS-30CC 3.0M CAT to CAT LS-15CL 1.5M CAT to Clamp LS-30CL 3.0M CAT to Clamp |
LS-15CC 1.5M CAT to CAT LS-30CC 3.0M CAT to CAT LS-15CL 1.5M CAT to Clamp LS-30CL 3.0M CAT to Clamp |
LS-15CC 1.5M CAT to CAT LS-30CC 3.0M CAT to CAT LS-15CL 1.5M CAT to Clamp LS-30CL 3.0M CAT to Clamp |
LS-15CC 1.5M CAT to CAT LS-30CC 3.0M CAT to CAT LS-15CL 1.5M CAT to Clamp LS-30CL 3.0M CAT to Clamp |
Recharge Time from Alternator |
Yes - 60 seconds |
Yes - 60 seconds |
Yes - 60 seconds |
Yes - 60 seconds |
Yes - 60 seconds Capacitors Only |
Yes - 60 seconds |
Yes - 60 seconds |
Recharge Time from supplied 240 volt Charger |
Standard Charge Time - 0%-100% Charge - 15 mins. Fast Charge Option - 0%-100% Charge 2.5 mins |
Standard Charge Time - 0%-100% Charge - 15 mins. Fast Charge Option - 0%-100% Charge 2.5 mins |
Standard Charge Time - 0%-100% Charge - 15 mins. Fast Charge Option - 0%-100% Charge 2.5 mins |
Standard Charge Time - 0%-100% Charge - 15 mins. Fast Charge Option - 0%-100% Charge 2.5 mins |
Standard Charge Time - 0%-100% Charge - 15 mins. Capacitors Only |
Standard Charge Time 0%-100% Charge - 5 mins. |
Standard Charge Time 0%-100% Charge - 5 mins. |
Fast Charger Option |
Hypastart Fast Charger Optional at extra Cost. Part Number HYPA-FCO |
Hypastart Fast Charger Optional at extra Cost. Part Number HYPA-FCO |
Hypastart Fast Charger Optional at extra Cost. Part Number HYPA-FCO |
Hypastart Fast Charger Optional at extra Cost. Part Number HYPA-FCO |
12 Volt 10 amp Lithium Battery Charger Included |
Fast Charger Standard |
Fast Charger Standard |
Proven Starting Examples |
CAT C27, 777 |
CAT C27, 777 |
CAT C27, 777 |
CAT C27, 777 |
CAT C27, 777 |
CAT 793D |
Komatsu 830E, CAT994F 24 Volt Loaders |
Known Limitations |
Most American 12 Volt trucks with 4 x 800 CCA Batteries on board - Durst Truckmaster will start these vehicles https://durst.com.au/product/maxion-truck-master-jump-starter-for-12v-trucks/ |
Most American 12 Volt trucks with 4 x 800 CCA Batteries on board - Durst Truckmaster will start these vehicles https://durst.com.au/product/maxion-truck-master-jump-starter-for-12v-trucks/ |
Most American 12 Volt trucks with 4 x 800 CCA Batteries on board - Durst Truckmaster will start these vehicles https://durst.com.au/product/maxion-truck-master-jump-starter-for-12v-trucks/ |
Most American 12 Volt trucks with 4 x 800 CCA Batteries on board - Durst Truckmaster will start these vehicles https://durst.com.au/product/maxion-truck-master-jump-starter-for-12v-trucks/ |
Most American 12 Volt trucks with 4 x 800 CCA Batteries on board - Durst Truckmaster will start these vehicles https://durst.com.au/product/maxion-truck-master-jump-starter-for-12v-trucks/ |
Can not Start Hitachi E3600 - See Hypastart X-6500 |
unknown |
Operating Temperatures |
"- 40 Degrees Celsius to + 70 Degrees Celsius |
"- 40 Degrees Celsius to + 70 Degrees Celsius |
"- 40 Degrees Celsius to + 70 Degrees Celsius |
"- 40 Degrees Celsius to + 70 Degrees Celsius |
"- 40 Degrees Celsius to + 70 Degrees Celsius |
"- 40 Degrees Celsius to + 70 Degrees Celsius |
"- 40 Degrees Celsius to + 70 Degrees Celsius |
Accessories |
Cordura Lead Bag available in small and large sizes. Waterproof Duffle bag, Protective Neoprene sleeve, Hypastart Trolley and Soft replaceable plastic handle. All available at extra cost |
Cordura Lead Bag available in small and large sizes. Waterproof Duffle bag, Protective Neoprene sleeve, Hypastart Trolley and Soft replaceable plastic handle. All available at extra cost |
Cordura Lead Bag available in small and large sizes. Waterproof Duffle bag, Protective Neoprene sleeve, Hypastart Trolley and Soft replaceable plastic handle. All available at extra cost |
Cordura Lead Bag available in small and large sizes. Waterproof Duffle bag, Protective Neoprene sleeve, Hypastart Trolley and Soft replaceable plastic handle. All available at extra cost |
Cordura Lead Bag available in small and large sizes. Waterproof Duffle bag, Protective Neoprene sleeve, Hypastart Trolley and Soft replaceable plastic handle. All available at extra cost |
Cordura Lead Bag available in small and large sizes. Waterproof Duffle bag, Protective Neoprene sleeve, Hypastart Trolley and Soft replaceable plastic handle. All available at extra cost |
Cordura Lead Bag available in small and large sizes. Waterproof Duffle bag, Protective Neoprene sleeve, Hypastart Trolley and Soft replaceable plastic handle. All available at extra cost |
