24 Volt 40 Amp Fully Automatic SwitchMode Battery Charger
- Premium Switchmode Battery Charger, Suitable for Automotive, Marine, Mobile Home or Caravan, Mobility Appliances,
- Solar, Deep Cycle, UPS Standby
- Battery types: Lead-acid/GEL/AGM/LiFEP04
Features
Microprocessor controller inside
Full range AC input
Power factor correction > 0.97
High efficiency
4 Stages charging I-Uo-U-Equalization
Battery charger and power supply selectable
Compact and light weight
Maintains batteries in perfect condition and prolong their useful life
Performance, Physical and Dimensional Properties
Input voltage range: 100-240VAC
Input frequency: 50-60Hz
Power factor correction: >0.97
Efficiency at 230VAC: >93%
Efficiency at 115VAC: >91%
Input current at 230VAC: 5.62A
Input current at 115VAC: 11.33A
Charge mode: Normal 3-Stage/Equalization 4-Stage
Output charging voltage: 28V/28.8V/29.6V,
Output float voltage: 27V/27.6V
Output power mode voltage: 26.4V
Output charge current: 0-40A
Equalization mode: 29.6V/31V (0-20A)
Half power mode (Silent mode): 0-20A
Battery connection: 3
Battery capacity: 400Ah
Operating temperature: -20°C ~ +50°C
Dimension (L x W x H): 327 x 210 x 75 mm
Weight: 3 kgs
Option: Remote control RC-600 or RC-601D
Option: Temperature compensation TF-100
Protection
Short circuit protection, Over voltage protection, over current protection, over temperature protection
